A recent leak suggested that the upcoming OnePlus Ace 7 would feature a built in cooling fan. Now, a tipster has shared alleged schematics of the smartphone, revealing more details about its cooling system.

Digital Chat Station shared the information in a Weibo post, claiming that the OnePlus Ace 7 will introduce a new dual airflow cooling system.

According to the tipster, the system will push hot air out through the sides while directing cool air towards the rear panel. The leaked schematics show the cooling fan positioned at the bottom right corner of the square camera module.

The phone is also expected to feature an AI thermal sensor and advanced optimizations similar to those used in desktop graphics cards. The cooling system is reportedly designed to reduce noise and prevent dust from entering the device.

The new setup is said to help the Snapdragon 8 Elite Gen 5 chipset deliver performance comparable to the Snapdragon 8 Elite Extreme Gen 6.

According to previous rumours, the OnePlus Ace 7 could feature a 6.78 inch LTPS OLED display with a 185Hz refresh rate, a triple rear camera system and a 9,000mAh battery.
